E-Bike System
Motor
Specialized 3.1 Motor, 105Nm torque, 810W power
Battery
Specialized Turbo 840Wh integrated battery
Display / Control Unit
MasterMind TCU with 2.2" high-resolution screen, fully customisable via Specialized app, compatible with Apple Find My
Charger
Specialized 4A charger
Frame & Geometry
Frame
Specialized M5 aluminium frame, 130mm travel, SWAT downtube storage, adjustable geometry, side-entry battery, 12x148mm UDH-compatible rear dropout
Seat Binder
Alloy, 38.6mm
Suspension
Fork
FOX 36 SL Performance, GRIP damper, 140mm travel, 44mm offset, 15x110mm
Rear Shock
FOX FLOAT Performance GENIE, Ride Dynamics developed, 2-position compression adjust, 190x45mm
Brakes
Front Brake
SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
Rear Brake
SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
Drivetrain
Shifters
SRAM Eagle 90T, single click, with MMX
Rear Derailleur
SRAM Eagle 90 T-Type
Cassette
SRAM GX Transmission XS-1275, 10–52t
Chain
SRAM 70 Transmission, 12-speed Flattop
Crankset
SRAM Eagle 70, BROSE/ISIS, 160mm, 32T
Chainring
SRAM 34T T-Type, 104 BCD, steel
Wheels & Tyres
Rims
Specialized hookless alloy, 30mm internal width, tubeless ready
Front Hub
Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28H
Rear Hub
Specialized alloy, sealed cartridge bearings, 6-bolt, 12x148mm thru-axle, 32H, XD driver
Spokes
DT Swiss Elemental
Front Tyre
Specialized Purgatory, GRID casing, T9 compound, 29x2.4
Rear Tyre
Specialized Purgatory, GRID Trail casing, T7 compound, 29x2.4 (S1: 27.5x2.4)
Inner Tubes
Standard, Presta valve
Cockpit
Stem
Alloy trail stem, 35mm clamp
Handlebars
Specialized alloy, 800mm width, 30mm / 40mm rise, 35mm clamp
Grips
Specialized trail grips
Saddle
Body Geometry Power Comp, steel rails
Seatpost
X-Fusion Manic, 34.9mm
- S1–S2: 125mm travel
- S3: 150mm travel
- S4: 170mm travel
- S5–S6: 190mm travel
Additional Features
Storage
SWAT internal downtube storage
Certification
UL 2849 (e-system) and/or UL 2271 (battery) certified
Weight
Weight
24.24 kg (size S3)
